Intel Core i7-13700K Unlocked Desktop Processor With Graphics

Brands:
SKU: CORE-I7-13700K-BOX Categories: , ,

39,675.00

Availability: Out of Stock

Out of stock

SKU: CORE-I7-13700K-BOX Categories: , ,

Description

  • 16 cores (8 P-cores + 8 E-cores) and 24 threads. Integrated Intel UHD Graphics 770 included
  • Performance hybrid architecture integrates two core microarchitectures, prioritizing and distributing workloads to optimize performance
  • Up to 5.4 GHz unlocked. 30M Cache
  • Compatible with Intel 600 series and 700 series chipset-based motherboards
  • Turbo Boost Max Technology 3.0, and PCIe 5.0 & 4.0 support. Intel Optane Memory support. No thermal solution included

Additional information

Essentials

Product Collection : 13th Generation Intel® Core™ i7 Processors
Code Name : Products formerly Raptor Lake
Vertical Segment : Desktop
Processor Number : i7-13700K
Lithography: Intel 7

CPU Specifications

Total Cores : 16
# of Performance-cores : 8
# of Efficient-cores : 8
Total Threads : 24
Max Turbo Frequency : 5.40 GHz
Intel® Turbo Boost Max Technology 3.0 Frequency : 5.40 GHz
Performance-core Max Turbo Frequency : 5.30 GHz
Efficient-core Max Turbo Frequency : 4.20 GHz
Performance-core Base Frequency : 3.40 GHz
Efficient-core Base Frequency : 2.50 GHz
Cache : 30 MB Intel® Smart Cache
Total L2 Cache : 24 MB
Processor Base Power : 125 W
Maximum Turbo Power : 253 W

Memory Specifications

Max Memory Size (dependent on memory type) : 128 GB
Memory Types : Up to DDR5 5600 MT/s, Up to DDR4 3200 MT/s
Max # of Memory Channels : 2
Max Memory Bandwidth : 89.6 GB/s
ECC Memory Supported : Yes

Graphics Specification

Processor Graphics : Intel® UHD Graphics 770
Graphics Base Frequency : 300 MHz
Graphics Max Dynamic Frequency : 1.60 GHz
Graphics Output : eDP 1.4b, DP 1.4a, HDMI 2.1
Execution Units : 32
Max Resolution (HDMI) : 4096 x 2160 @ 60Hz
Max Resolution (DP) : 7680 x 4320 @ 60Hz
Max Resolution (eDP – Integrated Flat Panel) : 5120 x 3200 @ 120Hz
DirectX* Support : 12
OpenGL* Support : 4.5
OpenCL* Support : 3.0
Multi-Format Codec Engines : 2
Intel® Quick Sync Video : Yes
Intel® Clear Video HD Technology : Yes
# of Displays Supported : 4

Expansion Options

Direct Media Interface (DMI) Revision : 4.0
Max # of DMI Lanes : 8
Scalability : 1S Only
PCI Express Revision : 5.0 and 4.0
PCI Express Configurations : Up to 1×16+4, 2×8+4
Max # of PCI Express Lanes : 20

Package Specifications

Sockets Supported : FCLGA1700
Max CPU Configuration : 1
TJUNCTION : 100°C

Warranty

3 Years
