NZXT H510 Flow Mid Tower Case (Matte Black)

SKU: CA-H52FB-01 Category:


Availability: Out of Stock

Out of stock

SKU: CA-H52FB-01 Category:


This compact mid-tower is an ideal case for high-performance builds and features a perforated front panel for maximized airflow. The H510 is easy to build in and offers flexibility for a variety of ATX parts.

  • An optimized perforated top panel delivers increased airflow to your system for improved temperatures
  • Iconic cable management bar and uninterrupted tinted tempered-glass side panel
  • Cable routing kit with pre-installed channels and straps
  • Two Aer F120mm fans and removable filters on all air intakes
  • Removable bracket designed for radiators up to 280mm

Additional information

Case Type

Motherboard Support

Mini-ITX, MicroATX, ATX


SGCC Steel, Tempered Glass


Height: 460 mm
Width: 210 mm
Depth: 428 mm

Net Weight

6.6 kg


Max CPU Cooler Clearance: 165 mm
Max GPU Clearance: 360 mm
Front Fan & Radiator Clearance: 60 mm
Cable Management: 19 – 23 mm

Front I/O Ports

USB 3.2 Gen 1 Type-A: 1
USB 3.2 Gen 2 Type-C: 1
Headset Audio Jack: 1

Expansion Slots


Drive Bays

2.5": 2 + 1
3.5": 2 + 1

Pre-Installed Fans

Front: 1 x Aer F 120mm (Case Version)
Rear: 1 x Aer F 120mm (Case Version)

Fan Specs

Model: Aer F 120mm (Case Version)
Speed: 1,200 ± 200RPM
Airflow: 50.42 CFM
Noise: 28 dBA
Bearing: Rifle Bearing
Fan Connector: 3-pin

Fan Support

Front: 2 x 120mm / 2 x 140mm
Top: 1 x 120mm / 1 x 140mm
Rear: 1 x 120mm
Filters: All air intake

Radiator Support

Front: 280mm
Rear: 120mm


2 Years
